F.43
TE 250 - 310 2012 I.E. / TE 250 - 310 2012 I.E. USA
TC 250 2012 - TC 250 2012 I.E. USA
TXC 250 - 310 2012 I.E. USA
ENGINE DISASSEMBLY
Workshop Manual Ed. 12-2011
Crankcase disassembly
- Remove the nine screws (1) from the left crankcase (2) (8 mm wrench).
Important: the screws (1) are not all the same length. Refer to gure
"A" on assembly to ensure correct installation.
FIG. "A"
a1= 6x60 mm
a2= 6x55 mm
a3= 6x70 mm
a4= 6x90 mm
