109706 10/08 3-7
Hydraulic Line Connections
NOTES:
1. See “Hydraulic routing” on page 10-8.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 601521 N/A 1 HOSE MANIFOLD BLOCK TO OIL COOLER
2 601583 N/A 1 HOSE MANIFOLD BLOCK
3 601001 601001 7 SPRING CLAMP .75" DIA
4 601522 N/A 1 HOSE RETURN COOLER TO MANIFOLD BLOCK
5 601584 N/A 1 HOSE MANIFOLD BLOCK
6 601617 601617 2 SPRING CLAMP 5/8" DIA.
7 601519 N/A 1 HOSE CASE DRAIN LEFT MOTOR
8 601518 N/A 1 HOSE CASE DRAIN RIGHT MOTOR
9 601570 N/A 1 HOSE RETURN MANIFOLD BLOCK TO RESERVOIR
10 601520 N/A 1 HOSE CASE DRAIN PUMP TO MANIFOLD
11 700484 700484 2 CLAMP HOSE (FS)
12 601517 N/A 1 HOSE SUCTION HDZ HYDRO
13 601494 N/A 1 TUBE TP-TM RT LOOP
14 601495 N/A 1 TUBE BP-BM RT LOOP
15 601496 N/A 1 TUBE TP-TM LT LOOP
16 601497 N/A 1 TUBE BP-BM LT LOOP
N/A 601498 1 HYDRO KIT HDZ (INCLUDES 1, 2, 4, 5,7-10, & 12-16)
