HUSTLER Diesel Z Parts Manual

10-6 109706 10/08
Throttle cable connection (FIG. 14).
Fuel lines
Fuel priming bulb (with arrow facing up) and right side fuel line routing (FIG. 15 & FIG. 16)
FIG. 13 FIG. 14
FIG. 15
THROTTLE CABLE
THROTTLE CABLE
CLIP
FROM
RIGHT SIDE
FUEL TANK
FUEL LINES
HYDRAULIC
LINES
TIE STRAP
FROM PRIMING
BULB TO PUMP
FUEL LINE
AIR HOSE
ON ENGINE
TIE STRAP
CLAMP
SCREWS
AS SHOWN
ORIENT THE
