HUSTLER Diesel Z Parts Manual

2-4 109706 10/08
Rivet Nut Installation
NOTES:
1. Service part includes Items 2 and 3 and decals. See “Tractor Decals” on
page 9-2.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 549139 109624 1 TRACTOR FRAME (72" SIDE DISCHARGE)
549121 109621 1 TRACTOR FRAME (66" SIDE DISCHARGE)
549113 108932 1 TRACTOR FRAME (60" SIDE DISCHARGE)
549105 109617 1 TRACTOR FRAME (54" SIDE DISCHARGE)
549758 110626 1 TRACTOR FRAME (72" REAR DISCHARGE)
549618 110623 1 TRACTOR FRAME (60" REAR DISCHARGE)
549766 110628 1 TRACTOR FRAME (54" REAR DISCHARGE)
2 808493 808493 4 3/8-16 THREAD RIVET NUT
3 600961 600961 4 1/2-13 THREAD RIVET NUT
1
2
3
3
1
