109706 10/08 2-3
Footrest Assembly
NOTES:
1. Do not tighten, Item 5 (109104 Floor Plate) must be able to pivot on
these bolts.
2. Service part includes Items 1 and 2 (step treads).
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 785485 785485 2 UPPER STEP TREAD 5.00
2 785493 785493 2 LOWER STEP TREAD 9.00
3 056069 056069 2 CS .375-16X .625 HX G5
4 767954 767954 8 FW .406X .812 X.060 SAE
5 549410 109104 1 FLOOR PLATE HDZ
6 601571 601571 2 VIBRATION MOUNT
7 781880 781880 4 BUMPER .500X 1.00X .31
8 109399 109399 1 FLOOR PAN MOUNT STRAP
9 086660 086660 4 NT .375-16 HXZY NL
10 054502 054502 2 NT .375-16 HX GRD 5 ZNY
11 052860 052860 2 CS .375-16X1.250 HX G5
