109706 10/08
7-35
Spindle Assembly—796680X
NOTES:
1. Install
upper
b
earing with extended inner race up.
2. Install
lower
bearing with extended
inner race down.
ITEM
NO.
SERVICE
PA
R
T
N
O
.
MFG
.
P
ART NO.
QTY
.
DESCRIPTION
1
077123
N/A
2
BEARING W/O COLLAR
2
766204
N/A
1
BLADE SPINDLE BUSHING
3
034843
N/A
1
CAST SPINDLE HOUSING
4
012005
N/A
1
GREASE FITTING
5
600893
N/A
1
BEARING DUST COVER
6
796698
N/A
1
SPINDLE SHAFT
1
2
1
6
2
3
4
1
5
94
96
