PTO clutch wire routing (FIG. 2 & FIG. 3)

Orient the hose clamp on the air filter to engine hose so that it is accessible for maintenance (FIG. 4). Orient the pre-

cleaner cap with the vent notch facing downward and away from the operator (FIG. 5).

Wire harness and cable routings

Battery cable connections (FIG. 6 & FIG. 7).

FIG. 2 FIG. 3

FIG. 4 FIG. 5

FIG. 6 FIG. 7

TIE STRAP

CLUTCH WIRE

TIE STRAP

CLUTCH WIRE

SCREW

CLAMP

AIR FILTER

PRECLEANER

NOTCH

NEG. BATTERY

CABLE

POS. BATTERY

CABLE

FUSE

BEND TERMINAL

SO THAT CABLE

CLEARS THE

ENGINE MOUNT
