109706 10/08 5-11
Firewall & ROPS Assembly
NOTES:
1. Assemble Item 6 (ROPS Stop) on right post of ROPS only.
2. Service part includes decals. See “Tractor Decals” on page 9-2.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 601443 601443 1 ROPS DZ FOLDING
2 601470 601470 2 KNOB HAND FOR ROPS
3 601471 601471 2 LYNCH PIN W/ LANYARD
4 061812 061812 5 CS .500-13X3.500 HX G5
5 023317 023317 2 NT .500-13 UNT LK G5 ZN
6 601472 601472 1 ROPS STOP
7 077859 077859 1 CS .500-13X3.250 HX G5
8 055939 055939 4 CS .250-20X .750 HX G5
9 768515 768515 16 FW .281X.625X.051/.080H
10 549352 109547 1 FIREWALL W/A HDZ
11 109401 109401 1 SCREEN OIL COOLER
12 068551 068551 8 NT .250-20 HXZY NL
13 601356 601356 1 OIL COOLER 8" FAN ALUM
14 601357 601357 1 FAN ELECTRIC 8" 12VDC
15 601538 601538 4 ELECTRIC FAN FOOT
16 056077 056077 4 CS .250-20X1.000 HX G5
17 601069 601069 4 CN .312-18X.200 MAX THK
18 781567 781567 4 NT .500-13 HX G8 ZY NL
19 767962 767962 1 FW .531X 1.063X.090 SAE
20 601559 601559 1 SEAT PAD
