54" Rear Discharge Deck Assembly
NOTES:
1. Factory assembled in top hole for shipping purposes.
2. Includes Items 12 through 14 and 16.
3. Service part deck includes decals, see ‘‘54" Rear Discharge Deck
Decals’’ on page 9-10.
4. When installing Items 19 and 21, Item 21 should be on top of Item 19.
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY. DESCRIPTION
1 549584 110441 1 54" REAR DISCHARGE DECK W/A
2 109490 109490 1 DISCHARGE SHIELD
3 768523 768523 10 FW .343 X .687 X .051/.080 HD ZN
4 086660 086660 12 NT .375-16 HX LK NY
5 767954 767954 32 FW .406 X .812 X .060 SAE HD ZN
6 710194 710194 6 CB .375-16X 1.50 STD G5
7 601069 601069 4 CN .312-18X.200 MAX THK
8 015495 015495 2 STRAIGHT GREASE FITTING
9 349803 349803 1 PUSHER
10 036244 036244 20 CS .375-16 X 1.00 HX G5 ZN
11 107975 107975 1 54" REAR DISCHARGE FRONT ANGLE
12 781708 N/A 4 CS .500-13 X 4.25 HX G5 ZN
13 767962 N/A 8 FW .531 X 1.063 X.090 SAE HD ZN
14 053199 N/A 4 NT .500-13 HX JAM ZN
15 781567 781567 4 NT .50-13 HXZY NL
16 031997 N/A 4 ANTI-SCALP WHEEL
17 109486 109486 1 CLAMP ANGLE LS
18 109487 109487 1 CLAMP ANGLE RS
19 601483 601483 2 RD SIDE FLAP
20 108816 108816 2 CLAMP BRACKET
21 601017 601017 2 RD REAR FLAP
22 109543 109543 2 EXTENSION BRACKET LS 54"
23 109542 109542 2 EXTENSION BRACKET RS 54"
24 025395 025395 6 CB .375-16X 1.00 STD CD
25 109482 109482 1 CHUTE BRACKET RS
26 109483 109483 1 CHUTE BRACKET LS
27 778399 778399 2 FW .781 X 1.375 X .250 ZNYC
28 016253 016253 4 CB .312-18 X .750 FUL ZN
29 058776 058776 10 NT .312-18 HXZY NL
30 107978 107978 2 AIR FLOW BAFFLE
31 037887 037887 6 CB .312-18X 1.000 FUL Z
32 109491 109491 1 SHIELD MTG ANGLE
33 600994 600994 14 RIVET NUT, 3/8-16 THREAD
788166 788166 4 ANTI-SCALP WHEEL ASSEMBLY
