Huvitz CDR-3100 - Motor Board - Right Side; CAN Board (Interior Type)

- 35 -
3. Motor board – right side
PHOTO SENSOR(J15~J23)
LIMIT
SWITCH
J26 J25 J24 J23 J22 J21 J20 J19 J18 J17 J16 J15
PD LED
J11 J14J12
J9 J8 J7 J6 J5 J4 J3
MOTOR(J3~J9, J11,J12,J14)
J2
POWER
J13
RS232
& CAN
MOTOR BOARD RIGHT
J10
J1
JTAG-ICE
EEPROM
12
SIG
3.3V
12
SIG
3.3V
13
GND
SIG
13
GND
SIG
3.3V
5V
TX
RX
GND
1
4
5V
1
5
24V
24V
GND
GND
J3~J9,J11,J12,J14
51
A
B
A-
B-
COM
MOTOR
4. CAN board (interior type)
POWER
&
RS232
J1
CAN BOARD(INTERIOR)
J2
J3
CAN
COMMUNICATION
PORT(CANH, CANL)
RX
1
6
TX
NC
NC
GND
5V CANL
CANH
CANL
CANH
1
2
1
2
