Huvitz CDR-3100 - Wiring Diagram and Board Description; Junction Box

- 33 -
B. Wiring diagram and board description
1. Junction box
TERMINATOR
J6 J5 J4 J2
CONVERTER
BOX1
PHOROPTOR
HEAD
J1
CONVERTER
BOX2
J3
OPERATION
PANEL
SMPS
FUSE1
(5V)
FUSE2
(7.2V)
FUSE3
(24V)
AC IN
7.2V
GND
5V 5V 5V
GND GND GND GND GND
24V 24V
1
12
CANH
CANL
5V
24V 24V
GND GND GND
1
8
1
6
CANH
CANL
5V
7.2V
GND GND
CANH
CANL CANL CANL
CANH CANH
1
2
1
2
1
2
