HV Diagnostics HVA 34 - Page 20

User Manual
HV Diagnostics Page 20 Rev 9.0
Setting Options Example
USB Flash
“USB Flash” defines the status of communication
port (12).
• USB Flash :Yes (for USB Flash Adapter)
• USB Flash: No ( for RS232)
 Note: Set USB Flash Selection to “no” prior
to firmware upgrades or RS232
communication to a PC
System Info
“System Info” displays HVA characteristics. This
information cannot be modified by the operator:
• Version: Installed HVA Firmware
• SN: HVA unit serial number
• Last Cal: Date of last calibration
• Ctrl.: Temperature
Instrument Settings
Set Date and Time
Reporting: Basic
Startup: Main Menu
Distance Unit: Meter
Language: English
USB Flash: yes
System Info
MAIN
System Info
Version 1.24.1
SN: 0123456789012
Last Cal. 12/02/2004
Ctrl. 80°F – PU 82°F
MAIN
