User Manual
Rev 9.0 Page 39 HV Diagnostics
Report Naming Instructions
To enter the report information, some steps (i.e. steps R4-R13) require
the operator to enter a user selected name. If no name is entered, the
corresponding category appears blank in the report.
Possible entries include:
• A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
• . , ; : “ # - + /
• 0 1 2 3 4 5 6 7 8 9
• To activate naming: Rotate Navigation Knob (5), then Push in/click.
• To select characters: Rotate Knob (5) clockwise
• To DELETE: Rotate Knob (5) counter clockwise until < symbol
appears
• To SPACE: Rotate Knob (5) counter clockwise until _ symbol
appears
• To confirm: double click Knob (5)
Entering Report Information
The HVA guides the user through a series of questions dependent on
the report type already set in “Instrument Settings”. These steps are
independent of the test mode, as the user has not yet selected “Manual”
or “Automatic”. Note that although some of the following steps (i.e. R1 –
R3) require entry of identical information as in “Configuring Auto Test.
Sequence” (i.e. steps AS 2, AS 3 and AS 4), these steps are not
identical!
Steps R 1-R 13 lists the report information that the HVA asks the user
to enter when the “Extended” reporting mode is active.
Step Procedure (Reporting) Example
DUT : 1,0kV Cable XPLE
Report Title
Circuit / Line ID
circuit
Start New Report
MAIN PREV NEXT
DUT : 1,0kV Cable XPLE
Report Title
Circuit / Line ID
circuit
Start New Report
MAIN PREV NEXT
DUT : 1,0kV Cable XPLE
Report Title
Circuit / Line ID
circuit x
Start New Report
MAIN PREV NEXT
DUT : 1,0kV Cable XPLE
Report Title
Circuit / Line ID
Circuit A
Start New Report
MAIN PREV NEXT
DUT : 1,0kV Cable XPLE
Report Title
Circuit / Line ID
circuit A
Start New Report
MAIN PREV NEXT
