Impact of device position vis-à-vis the transmitter
(router or AP)
The device uses a flat antenna similar to mobile telephones or laptops, while the connection
points generally use multi-directional antennas (rods). Flat antennas have the same or better
sensitivity as multi-directional antennas (the transition connector is omitted), but its primary
disadvantages include sensitivity to the positioning of the device vis-à-vis the connection point.
WiFi AP
WiFi AP
WiFi AP
WiFi AP
Reset
Power
5V
WiFi
DI1Port2
Alarm DI
Port1
Alarm SENS
DI2Ethernet
Temp/Humidity
