Hy-Gain MK2 - Element Assembly and Antenna Dimensions

Item
No.
Designator
Part
Number
Description
Item
No.
Designator
Part
Number
Description
1 R1 871098 1'/<" x 83" 11 RDE-3 190603 1" x 8"
2 R2 190303
1'/e"
x 52"
10
FDE-2 & D-2 190312
1'/e"
x 31
%e"
3
R3 171153
7
/,6"
x 37" 9 FDE-3 & D-3 190606 1 "
4 R2-1 190206 %" x 55" 12 FDE-4 & D-4 178558
7
/,6
"
x 28"
5 R2-2 190006
%"
x
26"
13 15 Meter Trap 878694 15 Meter Trap
6 R2-3 & RDE-4 176216
7
/,6"
x 32" 14 10 Meter Trap 878749 10 Meter Trap
7 RDE-1, FDE-1, D-1 190900 1'/<" x 48" 15 15 Meter DE Trap 878637 15 Meter DE Trap
8 RDE-2 190311
1'/6"
x 36"
Figure 6 Element Assembly and Antenna
Dimensions
Assemble the remainder of the 15-20 meter reflector, as shown in
Figure 6, using #16, #10 and #6 tubing clamps. Use trap Part Number
878694 and install with the drain holes facing the ground. Use Figure 5
and Detail A as guides. Tighten all element tubing clamps and recheck
all dimensions. DO NOT OVERTIGHTEN.
