3.9
LUBRICATION
The V-25APC was designed with a goal to minimize the maintenance required so as to reduce downtime. We recommend
that periodic lubrication be done once a month using any general purpose grease. The following photos show the location
of grease ttings that should be lubricated monthly.
In addition to the grease ttings shown, it is good practice to maintain a constant greased surface on the vise ways and
moving parts. As the vises are precision t to the vise table, the constant friction of metal to metal can be effectively allevi-
ated with the application of a general purpose grease. If the saw is left for long periods without use, an effective coating of
grease will prevent metal to metal adhesion and rust.
Carriage Runner Blocks (x4)
Swing Cylinder Trunnion (x4)
Head Pivot Bearing (x2)
&
Idler Tension Arm Bushing
Moveable Jaw Post (x2)
Barfeed Runner Blocks (x4)
