Hyd-Mech V-25APC - SECTION 8 - SPECIFICATIONS; V-25 APC BANDSAW SPECIFICATIONS

8.1
SECTION 8 - SPECIFICATIONS
V-25APC BANDSAW SPECIFICATIONS
Capacity
at 90º 25”x 30.5”(635mm x 775mm)
at 45º 21”x 25”(534mm x 635mm)
at 30º RH 14.5”x 25”(368mm x 635mm)
at 30º LH 13.5”x 25”(343mm x 635mm)
Bundling clamp is full capacity at 90º
Cant Angle 5.6º
Blade
Length 21’ 1/2” (6414mm)
Width 1 1/5” (38mm) Wide x .050 (1.3mm) Thk.
Blade Speed variable 75 - 350 sf/min (23 - 106 m/min)
Blade Guides
Carbide pads, spring loaded, zero clearance, with positively maintained parallelism
Integrally mounted entry rollers
Blade Wheel Dia.
Drive Wheel 32” (813mm)
Idler Wheel 24” (610mm)
Blade Drive 10 HP (7.5 kW)
Hydraulic System
Power 3 HP (2.2 kW)
Pressure 1000 psi (6895 kPa)
Tank 7 U.S. Gal.(26.5 liters)
Coolant System
Tank Capacity 38 US Gal (144 liters)
Usable Capacity 28 US Gal (106 liters)
Vises
Hydraulic Full stroke
Adjustable Force 1000 - 3300 lbs (454 - 1497 Kg)
Table Height 44” (1118mm)
Maximum Workload
10,000 lbs (4536 Kg) applied to table.
Based on .030” (0.76 mm) allowable table deection , safety factor of 4 on structure yield.
Machine Weight 9500 lbs (4309 Kg)
Barfeed Weight 4500 lbs (2041 Kg)
