17.2 ETS 3800 for external sensor probe
Input data
Measuring element PT 100 (TFP 100)
Measuring range
1)
-30 .. 150 °C (-22 .. 302 °F)
Sensor connection, separate
temperature probe
Female cable connection M12x1, 4 pole
Output variables
Switching outputs PNP transistor switching outputs
Switching current: max. 250 mA each switch output
(ohmic resistance)
Switching cycles: > 100 million
Analogue output, permitted load
resistance
selectable: 4 .. 20 mA resistance max. 500 Ω
0 .. 10 V resistance min. 1 kΩ
corresp. in each case to -30 to +150 °C
Accuracy (at room temperature)
≤ ± 1.0 °C (≤ ± 2.0 °F)
( + Error external temperature sensor)
Temperature drift (environment)
≤ ± 0.015 % FS / °C (≤ ± 0.0085 % FS / ° F)
Repeatability
≤ ± 0.25 % FS max.
Environmental conditions
Operating temperature range -25 .. + 80 °C (-13 .. 176 °F)
(-25 .. +60 °C [ -13 .. +140 °F] für UL-Spec.)
Storage temperature range -40 .. + 80 °C (-40 .. 176 °F)
- mark EN 61000-6-1 / 2 / 3 / 4
mark
2)
Certificate no.: E318391
Vibration resistance acc. to
DIN EN 60068-2-6 at 0 .. 500 Hz
≤ 10 g
Shock resistance to
DIN EN 60068-2-27 (11 ms)
≤ 50 g
Protection type to DIN EN 60529
3)
IP 67
Other data
Supply voltage
when applied acc. to UL specifications
9 .. 35 V DC, if PIN 2 = SP 2
18 .. 35 V DC if PIN 2 = analogue output
– limited energy – according to 9.3 UL 61010; Class 2,
UL 1310/1585;LPS UL 60950
Residual ripple of supply voltage ≤ 5 %
Current consumption ≤ 0.535 A with active switching outputs
≤ 35 mA with inactive switching outputs
≤ 55 mA with inactive switching output
and analogue output
Display 4-digit, LED, 7-segment, red,
height of digits 7 mm
Weight ~ 87 g (connector and probe not included)
Note: Reverse polarity protection of the supply voltage, excess voltage, override and short circuit
protection are provided.
FS (Full Scale) = relative to complete measuring range
1)
Depending on the temperature range of the connected temperature sensor, the indication
range of the ETS 3000 may be reduced.
2)
Environmental conditions according to 1.4.2 UL 61010-1; C22.2 no. 61010-1
3)
with mounted mating connector in corresponding protection type
