Hydac ETS 3000 Series - Page 77

ETS 3000 IO-Link 35
Stand: 28.04.2020 HYDAC ELECTRONIC GMBH Mat. Nr.: 669904 D
Standard Variable "Standard Command" index=2 id=V_SystemCommand
data type: 8-bit UInteger
allowed values: 128 = Device Reset, 129 = Application Reset, 130 = Restore Factory Settings, 160 = Reset Primary
Min/Max, 164 = Reset All Min/Max
access rights: wo
modifies other variables
octet 0
bit offset 7 - 0
element bit 7 - 0
Variable "BDC1 Thresholds" index=60 id=V_Bdc1Thresholds
data type: 32-bit Record (subindex access not supported)
access rights: rw
modifies other variables
excluded from data storage
subindex
bit
offset
data type
allowed
values
default
value
mod. other var. name description
1 16 16-bit Integer
See
11.2
188 V_PrimaryValueSp1 Setpoint SP1
Lower limit of
RP / FL in C
2 0 16-bit Integer
See
11.2
250 V_PrimaryValueSp1 Setpoint SP2
Upper limit of
SP / FH in C
SP = switch point RP = switch-back point FL = pressure window lower value FH = pressure window upper value
octet 0 1 2 3
bit offset 31 - 24 23 - 16 15 - 8 7 - 0
subindex 1 1 2 2
element bit 15 - 8 7 - 0 15 - 8 7 - 0
Standard Variable "Device Access Locks" index=12 id=V_DeviceAccessLocks
data type: 16-bit Record (subindex access not
supported)
access rights: rw
subindex bit offset data type name description
1 0 Boolean
Parameter (write)
Access Lock
2 1 Boolean Data Storage Lock
Datenhaltung (Subindex 2) ist aus
Kompatibilitätsgründen vorhanden und sollte immer auf
„False“ stehen, um unerwartetes Verhalten beim Data
Storage zwischen Master und Gerät zu vermeiden.
3 2 Boolean
Local
Parameterization
Lock
4 3 Boolean
Local User Interface
Lock
