40 ETS 3000 IO-Link
Stand: 28.04.2020 HYDAC ELECTRONIC GMBH Mat. Nr.: 669904 D
Octet 1
bit offset 15 14 13 12 11 10 9 8
subindex 1
element bit 7 6 5 4 3 2 1 0
Octet 2
bit offset 7 6 5 4 3 2 1 0
subindex / / / / / / / / / / / / / / / / / / / / / / / / 2 3 4 5
Variable "Primary Maximum Value" index=92 id=V_PrimaryMaxValue
data type: 24-bit Record (subindex access not supported)
access rights: ro
dynamic
subindex
bit
offset
data type
default
value
mod.
other var.
name description
1 8 16-bit Integer 0 Process Value
2 2 Boolean false Overflow
Octet 0
bit offset 23 22 21 20 19 18 17 16
subindex 1
element bit 15 14 13 12 11 10 9 8
Octet 1
bit offset 15 14 13 12 11 10 9 8
subindex 1
element bit 7 6 5 4 3 2 1 0
Octet 2
bit offset 7 6 5 4 3 2 1 0
subindex / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / 2 / / / / / / / / / / / /
Process Data Formatting
Formatting for Process Data id=PI_PdIn
Subindex 1:
Subindex 2:
Subindex 3: * 0.1 + 0 °C Dec.1
Events
Code Type Name Description
36002 (0x8ca2) Error User setup error User setup is corrupt, device is running with factory settings
36016 (0x8cb0) Error
Primary value signal
error
Primary value update failed, device output is temporarily disabled
36032 (0x8cc0) Warning
Primary value out of
range
Primary value is below or above its valid range and limited to the
corresponding lower or upper value
