9-48: Assemblies and Parts Lists
Figure 9-34. 100 Gallon Universal Recovery Tank (URT) Assembly
610-003-759 Rev. C
19
2X
20
2X
27
4X
39
3X
29
3X
30
2X
15
4
31
2X
22
2X
5
41
34
2X
11
2
33
23
10
25
21
4X
41
4X
12
41
4X
32
4X
21
4X
41
4X
12
3
41
4X
34
4X
35
9
42
2X
36
40
2X
8
14
000-081-332
LABEL, MAINTENANCE AND LUBE SCHEDULE
000-157-091
SWITCH, FLOAT LEVEL (AWDS)
000-052-763
NIPPLE, 1-1/2" NPT CLOSE S/S
000-169-022
VALVE, 1-1/2" FULL PORT BALL
000-052-226
INSERT, 1-1/2" NPT X 1-1/2" BARB
1
3
24
26
28
A
1
A2
TORQUE TO 40 FT LBS
TORQUE TO 60 FT LBS
TORQUE TO 50 FT LBS
16
6
37
7
17
38
18
22
4X
40
4X
34
4X
13
14
C
DETAIL VIEW A
NOTES:
1.
LOWER FLOAT SWITCH IS ONLY USED WHEN AWDS IS INSTALLED.
2.
ITEMS
21
AND
24
ARE NOT USED WHEN AWDS IS INSTALLED.
3.
ITEM IS PART OF LABEL SET #000-081-535.
4. SEE ENG-45975 OR ADHESIVE MATERIAL PRODUCTION LINE
REFERENCE CARD FOR SEALANT INFORMATION.
2
2
ITEM NO.
QTY.
DESCRIPTION
MATERIAL
PART NO.
42 2
WASHER, 3/8" FLAT RUBBER BACKED
S. STEEL
000-174-029
41 17
WASHER, 1/4" FLAT S/S
S. STEEL
000-174-003
40 6
WASHER, 1/4" FLAT RUBBER BACKED
18-8 S. STEEL
000-174-060
39 3
WASHER, #10 FLAT RUBBER BACKED
18.8 S. STEEL 000-174-036
38 1
VALVE, 12 VOLT SOLENOID 1200 PSI
BRASS
000-169-082
37 1
TEE, 1/4" NPT BRANCH M-F-F
BRASS
000-052-090
36 1
TANK, 100 GAL UNIVERSAL RECOVERY - COATED E-01
ALUMINUM
000-159-129
35 1
SWITCH, FLOAT LEVER
VARIOUS
000-157-091
34 10
SCREW, 1/4"-20UNC x 1.00" LG. HEX HEAD
S. STEEL
000-143-002
33 1
SCREW, 1/4"-20UNC X 3/8" LG. THUMB - BRASS
BRASS
000-143-787
32 4
SCREW, 1/4"-20UNC X 1.25" LG. HEX HEAD S/S
S. STEEL
000-143-010
31 2
SCREW, #8-32UNC x 0.75" LG. BINDER HEAD
S. STEEL
000-143-051
30 2
SCREW, #6-32UNC x 0.50" LG. BUTTON HEAD
18-8 S. STEEL
000-143-539
29 3
SCREW, #10-24UNC x 0.50" LG. HEX HEAD
S. STEEL
000-143-126
28 1
SACRIFICIAL ANODE, MAGNISIUM
VARIOUS
000-079-226
27 4
RIVET, AB8-6A ALUMINUM POP
ALUMINUM
000-140-023
26 1
PLUG, 1-1/4" NPT BRONZE
BRONZE
000-106-046
25 1
PLUG, 1-1/2" NPT BRONZE
BRONZE
000-106-019
24 1
PLUG, 1" NPT BRONZE
BRONZE
000-106-049
23 1
PLATE, BLOWER FLAT FILTER - ZR
5052-H32
000-105-785
22 6
NUT, 1/4"-20UNC NEOPRENE WELLNUT
NEOPRENE
000-094-113
21 8
NUT, 1/4"-20UNC HEX NYLOCK
S. STEEL
000-094-009
20 2
NUT, #8-32UNC HEX NYLOCK
AISI 304
000-094-059
19 2
NUT, #6-32UNC HEX NYLOCK
S. STEEL
000-094-063
18 1
NIPPLE, 3/8" NPT x 1/4" NPT HEX
BRASS
000-052-073
17 1
NIPPLE, 3/8" NPT x 1/4" M SAE BRASS
000-052-662
16 1
NIPPLE, 1/4" NPT HEX BRASS
000-052-071
15 1
LATCH, BUNGEE
VARIOUS
000-086-008
14 2
INSERT, #44
BRASS
000-052-100
13 1
GROMMET, LARGE WIRING
RUBBER
000-060-002
12 2
GASKET, ADAPTER - URT
RUBBER
000-057-206
11 1
FILTER, RECOVERY TANK BASKET
VARIOUS
000-049-152
10 1
FILTER, FLAT - UNIVERSAL RECOVERY TANK VARIOUS
000-049-153
9 1
FILTER, AIR DEFLECTOR, URT - FABRICATED
5052-H32
000-049-154
8 1
ELBOW, 1/4" NPT STREET x 45°
BRASS
000-052-082
7 1
ELBOW, 1/4" NPT STREET
BRASS
000-052-085
6 1
ELBOW, 1/4" FPT x FPT
BRASS
000-052-088
5 1
CLAMP, 1/2" WIDE X 1/2" TUBE
VARIOUS
000-033-046
4 1
BLOCK, 6 POST TERMINAL
VARIOUS
000-012-002
3 1
ASSEMBLY, VACUUM RELIEF VALVE - URT
VARIOUS
610-026-724
2 1
ASSEMBLY, 100 GAL, RECOVERY TANK COVER w/ 2.5"
PORT E-01
VARIOUS
610-029-001
1 1
ADAPTER, Ø3.0 TANK TO x 90° BLOWER HOSE - CASTING
356 T-51/A356 T-51
000-001-135
LTR
REVISION DESCRIPTION
CODE
DATE
BY
CHKD
APPVD
B
MOVE DUMP VALVE TO FRONT;
-
6/1/2021
L.O.L.
C.I.R. C.I.R.
C
ONE 000-052-100 WAS 052-102.
BETA
06/07/2021
M.B.B.
C.I.R. C.I.R.
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
MACHINE
FINISH
125
SCALE: 1:4
SHEET 1 OF 1
PROPRIETARY INFORMATION
11015 47th Avenue West,
Mukilteo, Washington 98275
D
SIZE
BREAK ALL SHARP EDGES 0.005-.015
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
PART NUMBER
WEIGHT:
APPLICATION
NEXT ASSY
USED ON
610-003-759
REV
ASSEMBLY, 100URT 525 - E01
C
- - -
TITAN 525
750-011-759-10
- - - - - -
- - -- - -
- - - - - -
- - - - - -
C.I.R.
C.I.R.
L.O.L.
DRAWN
CHECKED
APPVD
05/10/2021
06/01/2021
06/07/2021
TOLERANCES
.X=
.1
.XX=
.03
.XXX=
.010
ANGULAR =
2°
CODE:
136.79
19
2X
20
2X
27
4X
39
3X
29
3X
30
2X
15
4
31
2X
22
2X
5
41
34
2X
11
2
33
23
10
25
21
4X
41
4X
12
41
4X
32
4X
21
4X
41
4X
12
3
41
4X
34
4X
35
9
42
2X
36
40
2X
8
14
000-081-332
LABEL, MAINTENANCE AND LUBE SCHEDULE
000-157-091
SWITCH, FLOAT LEVEL (AWDS)
000-052-763
NIPPLE, 1-1/2" NPT CLOSE S/S
000-169-022
VALVE, 1-1/2" FULL PORT BALL
000-052-226
INSERT, 1-1/2" NPT X 1-1/2" BARB
1
3
24
26
28
A
1
A2
TORQUE TO 40 FT LBS
TORQUE TO 60 FT LBS
TORQUE TO 50 FT LBS
16
6
37
7
17
38
18
22
4X
40
4X
34
4X
13
14
C
DETAIL VIEW A
NOTES:
1.
LOWER FLOAT SWITCH IS ONLY USED WHEN AWDS IS INSTALLED.
2.
ITEMS
21
AND
24
ARE NOT USED WHEN AWDS IS INSTALLED.
3.
ITEM IS PART OF LABEL SET #000-081-535.
4. SEE ENG-45975 OR ADHESIVE MATERIAL PRODUCTION LINE
REFERENCE CARD FOR SEALANT INFORMATION.
2
2
ITEM NO.
QTY.
DESCRIPTION
MATERIAL
PART NO.
42 2
WASHER, 3/8" FLAT RUBBER BACKED
S. STEEL
000-174-029
41 17
WASHER, 1/4" FLAT S/S
S. STEEL
000-174-003
40 6
WASHER, 1/4" FLAT RUBBER BACKED
18-8 S. STEEL
000-174-060
39 3
WASHER, #10 FLAT RUBBER BACKED
18.8 S. STEEL 000-174-036
38 1
VALVE, 12 VOLT SOLENOID 1200 PSI
BRASS
000-169-082
37 1
TEE, 1/4" NPT BRANCH M-F-F
BRASS
000-052-090
36 1
TANK, 100 GAL UNIVERSAL RECOVERY - COATED E-01
ALUMINUM
000-159-129
35 1
SWITCH, FLOAT LEVER
VARIOUS
000-157-091
34 10
SCREW, 1/4"-20UNC x 1.00" LG. HEX HEAD
S. STEEL
000-143-002
33 1
SCREW, 1/4"-20UNC X 3/8" LG. THUMB - BRASS
BRASS
000-143-787
32 4
SCREW, 1/4"-20UNC X 1.25" LG. HEX HEAD S/S
S. STEEL
000-143-010
31 2
SCREW, #8-32UNC x 0.75" LG. BINDER HEAD
S. STEEL
000-143-051
30 2
SCREW, #6-32UNC x 0.50" LG. BUTTON HEAD
18-8 S. STEEL
000-143-539
29 3
SCREW, #10-24UNC x 0.50" LG. HEX HEAD
S. STEEL
000-143-126
28 1
SACRIFICIAL ANODE, MAGNISIUM
VARIOUS
000-079-226
27 4
RIVET, AB8-6A ALUMINUM POP
ALUMINUM
000-140-023
26 1
PLUG, 1-1/4" NPT BRONZE
BRONZE
000-106-046
25 1
PLUG, 1-1/2" NPT BRONZE
BRONZE
000-106-019
24 1
PLUG, 1" NPT BRONZE
BRONZE
000-106-049
23 1
PLATE, BLOWER FLAT FILTER - ZR
5052-H32
000-105-785
22 6
NUT, 1/4"-20UNC NEOPRENE WELLNUT
NEOPRENE
000-094-113
21 8
NUT, 1/4"-20UNC HEX NYLOCK
S. STEEL
000-094-009
20 2
NUT, #8-32UNC HEX NYLOCK
AISI 304
000-094-059
19 2
NUT, #6-32UNC HEX NYLOCK
S. STEEL
000-094-063
18 1
NIPPLE, 3/8" NPT x 1/4" NPT HEX
BRASS
000-052-073
17 1
NIPPLE, 3/8" NPT x 1/4" M SAE BRASS
000-052-662
16 1
NIPPLE, 1/4" NPT HEX
BRASS
000-052-071
15 1
LATCH, BUNGEE
VARIOUS
000-086-008
14 2
INSERT, #44
BRASS
000-052-100
13 1
GROMMET, LARGE WIRING
RUBBER
000-060-002
12 2
GASKET, ADAPTER - URT
RUBBER
000-057-206
11 1
FILTER, RECOVERY TANK BASKET
VARIOUS
000-049-152
10 1
FILTER, FLAT - UNIVERSAL RECOVERY TANK
VARIOUS
000-049-153
9 1
FILTER, AIR DEFLECTOR, URT - FABRICATED
5052-H32
000-049-154
8 1
ELBOW, 1/4" NPT STREET x 45°
BRASS
000-052-082
7 1
ELBOW, 1/4" NPT STREET
BRASS
000-052-085
6 1
ELBOW, 1/4" FPT x FPT
BRASS
000-052-088
5 1
CLAMP, 1/2" WIDE X 1/2" TUBE
VARIOUS
000-033-046
4 1
BLOCK, 6 POST TERMINAL
VARIOUS
000-012-002
3 1
ASSEMBLY, VACUUM RELIEF VALVE - URT
VARIOUS
610-026-724
2 1
ASSEMBLY, 100 GAL, RECOVERY TANK COVER w/ 2.5"
PORT E-01
VARIOUS
610-029-001
1 1
ADAPTER, Ø3.0 TANK TO x 90° BLOWER HOSE - CASTING
356 T-51/A356 T-51
000-001-135
LTR
REVISION DESCRIPTION
CODE
DATE
BY
CHKD
APPVD
B
MOVE DUMP VALVE TO FRONT;
-
6/1/2021
L.O.L.
C.I.R. C.I.R.
C
ONE 000-052-100 WAS 052-102.
BETA
06/07/2021
M.B.B.
C.I.R. C.I.R.
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
MACHINE
FINISH
125
SCALE: 1:4
SHEET 1 OF 1
PROPRIETARY INFORMATION
11015 47th Avenue West,
Mukilteo, Washington 98275
D
SIZE
BREAK ALL SHARP EDGES 0.005-.015
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
PART NUMBER
WEIGHT:
APPLICATION
NEXT ASSY
USED ON
610-003-759
REV
ASSEMBLY, 100URT 525 - E01
C
- - -
TITAN 525
750-011-759-10
- - - - - -
- - -- - -
- - - - - -
- - - - - -
C.I.R.
C.I.R.
L.O.L.
DRAWN
CHECKED
APPVD
05/10/2021
06/01/2021
06/07/2021
TOLERANCES
.X=
.1
.XX=
.03
.XXX=
.010
ANGULAR =
2°
CODE:
136.79
