HydraMaster Titan 625 - Figure 9-2. Titan 625 with 100 Gallon URT

9-3: Assemblies and Parts Lists
Figure 9-2. TITAN 625 WITH 100 GALLON URT
750-011-759-10 Rev. B
1.0
BETWEEN BLOWER
& RECOVERY TANK
62.505
65.422
39.612
41.905
43.055
52.000
9
2
1
9
PART OF
9
NOTES:
1. ITEM NOT SHOWN.
1
1
1
1
1
1
1
1
1
B
LTR REVISION DESCRIPTION CODE DATE BY CHKD APPVD
A RELEASE DRAWING.
NEW
6/1/2021 L.O.L. C.I.R. C.I.R.
B ADDED 182-306D; UPDATED VIEWS.
-
10/19/2021 L.O.L. C.I.R. C.I.R.
ITEM NO. QTY. DESCRIPTION MATERIAL PART NO.
12 1 WAND, 1-1/2" X 13" EVO ALUMINUM VARIOUS 000-163-034
11 1 MANUAL, TITAN 625 DIGITAL VARIOUS 000-182-306D
10 1 LABEL SET, HM EQUIPPED VINYL 000-081-057
9 1 KIT, PARTS PACKAGE XL 575 VARIOUS 000-078-560
8 1 KIT, FUEL PUMP KUBOTA VARIOUS 000-078-579
7 2 HOSE, 2" X 50' VACUUM BLUE VARIOUS 000-068-065
6 1 HOSE, 1/4" X 50' M-F SOLUTION HI-PSI BLUE w/ SHUTOFF VALVE VARIOUS 000-068-198
5 1 HOSE, 1/4" X 50' M-F SOLUTION HI-PSI BLUE VARIOUS 000-068-199
4 1 HOSE, 1-1/2" X 10' WHIP BLUE VARIOUS 000-068-317
3 1 HOSE, 1-1/2" DUMP - BLUE VARIOUS 000-068-598
2 1 ASSEMBLY, 100URT 525 - E01 VARIOUS 610-003-759
1 1 ASSEMBLY, CONSOLE - TITAN 625 VARIOUS 610-050-759
D
C
B
A
A
B
C
D
1
2
3
4 5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
MACHINE
FINISH
125
SCALE: 1:8
SHEET 1 OF 1
PROPRIETARY INFORMATION
11015 47th Avenue West,
Mukilteo, Washington 98275
D
SIZE
BREAK ALL SHARP EDGES 0.005-.015
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
PART NUMBER
WEIGHT:
APPLICATION
NEXT ASSY USED ON
750-011-759-10
REV
TITAN 625 w/ 100 URT
B
TITAN 625 w/ 100URT
- - -
- - - - - -
- - -- - -
- - - - - -
- - - - - -
C.I.R.
C.I.R.
L.O.L.
DRAWN
CHECKED
APPVD
06/01/2021
10/19/2021
10/19/2021
TOLERANCES
.X= .1
.XX= .03
.XXX= .010
ANGULAR = 2°
CODE:
1020.429
