4-1: Operating Instructions

4 - Operating Instructions

This section describes how to operate the Titan 625, starting with a description of the

dash assembly (see Figure 4-1).

Automatic Automatic

Wastewater Wastewater

Disposal SwitchDisposal Switch

Temperature Temperature

Control DialControl Dial

Throttle

Cable

Pressure

Gauge

Temperature

Gauge

Pump Clutch

Switch

Power Switch with Guard

(START, RUN and OFF)

Pump-In System Pump-In System

SwitchSwitch

Vacuum Vacuum

GaugeGauge

MIL LED

Figure 4-1. Titan 625 Upper Dash Assembly
