7-1: Electrical System
7 - Electrical System
This section describes how the electrical system functions in the following manner:
Electrical System Information
Electrical Schematic
Wiring Diagram
ELECTRICAL SYSTEM INFORMATION
The Titan 625 electrical system operates on 12 - 14 V DC which is provided by the battery.
Battery levels are maintained by a 25-Amp alternator mounted on the engine.
When a new battery is installed, check that it is properly charged before installation
or damage to the charging system may occur.
Electronic Fuel Injection (EFI) System
EFI is an electronically-controlled fuel management system which is monitored by an
Electronic Control Unit (ECU). A Malfunction Indicator Light (MIL) will illuminate if problems
or faults are detected. Servicing by a Kohler authorized dealer is necessary.
Jump Starting
Follow all safety guidelines and procedures provided by battery manufacturer and/or
original equipment manufacturer (OEM). Failure to follow proper procedures may result
in serious personal injury and/or non-warrantable damage to engine’s EFI components.
