Hydropool Hot Tub - North America GFCI Installation Diagram

H Y D R O P O O L I N D U S T R I E S
11
NORTH AMERICA – GFCI INSTALLATION – TYPICAL
GRN WHITE
RED (HOT)
BLACK (HOT)
GRN (GROUND)
Front View of G.F.C.I. (Square D)
WHITE (HOT)
WHITE
WHITE
GRN (GROUND) GRN (GROUND)
RED (HOT) BLACK (HOT)
BLACK (HOT) RED (HOT)
RED (HOT)
BLK (HOT)
WHITE
WHITE
WHITE (NEUTRAL)
TBI
Bottom View of G.F.C.I.
(Square D)
BLACK (HOT)
RED (HOT)
GREEN (GROUND)
1
2
3
4
5
(NOT APPLICABLE IN EUROPE)
