H Y D R O P O O L I N D U S T R I E S
35
TO CHECK/CHANGE THE SET TEMPERATURE
The last measured temperature is constantly
displayed on the topside control. When either of these pads
is pressed once, the display will show the set temperature
as well as the words SET hEAT. Press either pad a
second time to increase or decrease the set temperature.
After 3 seconds the display will once again display the last
measured temperature.
The temperature can be adjusted from 26.0˚C to 40.0˚C in
0.5˚ increments
PUMPS / JETS FUNCTION
PUMP 1 (P1)
1st press – turns on low speed – the icon flashes
2nd press – turns on high speed – the icon is solid
3rd press – turns off pump – no icon displayed
When P1 low is already operating, the 1st press of the
pad puts the pump directly into high speed. Low speed
P1 starts automatically every 30 minutes to measure
water temperature (in STANDARD MODE only – see MODE
FUNCTION), when a filter cycle is activated, or when a
freeze condition is detected.
When P2, P3 or the blower is manually activated, P1 low
speed is automatically activated and operates until the
pump(s) or blower time out. If P2, P3 or the blower is turned
on even briefly, and then turned back off, P1 low will
operate for a minimum of 2 minutes.
PUMP 2 & 3 (P2 & P3)
1st press – turns on P2 – the icon is displayed while P2
and/or P3 are operating
2nd press – turns on P3
3rd press – turns off P2
4th press – turns off P3 – no icon displayed when P2 and
P3 are off
PUMPS AUTOMATIC TIME-OUT
P1 high speed, P2 & P3 – 15 minutes
P1 low speed – 4 hours
CLEAN-UP CYCLE
After P1 high speed is turned off either manually or
automatically, P1 low speed circulates the water for 1
hour.
SETTING THE SYSTEM CLOCK TIME
The SET TIME message flashes on the topside control display
upon initial start-up. This reminder will disappear once the
clock time is programmed.
Press then to enter the clock ‘set time’ mode.
Press or and the time will automatically increase
or decrease by 1 minute increments. Once you reach the
correct time, press either pad again to stop the sequence.
Press the pad to exit the clock ‘set time’ mode
OR
Press the pad again to continue to the filter cycle
programming mode (see below).
During normal operation, pressing the pad will display
the current time for 3 seconds.
FILTER CYCLES
Once the system clock time has been programmed, the
system will automatically activate P1 low speed to filter the
water for 2 hours twice each day. During the filter cycle, the
display will show FILTER 1 or FILTER 2.
FACTORY PRESET DEFAULT
FILTER 1 the system automatically activates P1 low to operate
from 8 AM to 10 AM
FILTER 2 the system automatically activates P1 low to operate
from 8 PM to 10 PM.
PROGRAMMING FILTER CYCLES
To change the factory default filter cycle settings:
Press then then
At this point SET START FILTER 1 will appear on the display
Press the or pad to change the filter start time
Press the pad again to proceed to the next screen
At this point SET STOP FILTER 1 will appear on the display
Press the or pad to change the filter stop time
Press the pad again to proceed to the next screen for
programming the second filter cycle start/stop times and
repeat previous steps
Press the pad again to exit the programming mode.
