The number and size of appropriate steam manifolds, as well
the nominal width of their respective steam and condensate
hoses, are found in the tables below.
HyLine:
CompactLine:
HeaterCompact/Kit:
CompactLine Kit:
HeaterLine:
* For units HL 6 - 12 and HC3-12 HygroMatik delivers one adapter DN40 / 25 (but not for
SPA applications)..
** For units HL 36 - 45 HygroMatik delivers one t-connector for separating the steam on
two steam manifolds.
***Hl 60.-90 are double units and consist of Hl 30-45 units.
Type Steam Manifold Steam Hose Condensate hose
HY05-HY17 1xDN25 DN25 DN12
HY05DS - HY17DS (for
SPA)
1xDN40 DN40 DN12
HY23-HY30 1xDN40 DN40 DN12
HY45-HY60 2xDN40 2xDN40 2xDN12
HY90-HY116 4xDN40 4xDN40 4xDN12
Type Steam Manifold Steam Hose Condensate Hose
C1-C17 1xDN25 DN25 DN12
C10-DS, C17DS
(for SPA)
1xDN40 DN40 DN12
C22, C30 1xDN40 DN40 DN12
C45** 2xDN40 DN40 DN12
C58 2xDN40 2xDN40 2xDN12
Type Steam Manifold Steam Hose Condensate Hose
HC02/Kit 1 xDN25 DN25 DN12
HC03-12* 1xDN25 DN25 DN12
HC03-12/Kit 1xDN40 DN40 DN12
HC16-27/Kit 1xDN40 DN40 DN12
HC3-27 (for SPA) 1xDN40 DN40 DN12
Type Steam Manifold Steam Hose Condensate Hose
C01 Kit - C06 Kit 1x25 DN25 DN9
C10 Kit - C17 Kit 1x25 DN25 DN12
C30 Kit 1x40 DN40 DN12
C45 Kit 2x40 DN40 DN12
Type Steam Manifold Steam Hose Condensate Hose
HL 6-12 * 1xDN25 DN25 DN12
HL 6-12
(for SPA)
1xDN40 DN40 DN12
HL 18-30 1xDN40 DN40 DN12
HL 36-45 ** 2xDN40 1xDN40 1xDN12
HL 60-90 *** 2x(2xDN40) 2x(1xDN40) 2x(1xDN12)
