Hynautic 04 Series - System Parts List - Copper Tubing

Page 17 of 36 Pages
MC-B5-S1 (Ball Handle) or MC-T5-S1 ("T" Handle)
MC-B5-S1D (Ball Handle) or MC-T5-S1D ("T" Handle)
MC-B5-S2 (Ball Handle) or MC-T5-S2 ("T" Handle)
MC-B5-S2D (Ball Handle) or MC-T5-S2D ("T" Handle)
MC-B5-S3 (Ball Handle) or MC-T5-S3 ("T" Handle)
MC-B5-S3D (Ball Handle) or MC-T5-S3D ("T" Handle)
MC-B5-T1 (Ball Handle) or MC-T5-S1 ("T" Handle)
MC-B5-T1D (Ball Handle) or MC-T5-T1D ("T" Handle)
MC-B5-T2 (Ball Handle) or MC-T5-T2 ("T" Handle)
MC-B5-T2D (Ball Handle) or MC-T5-T2D ("T" Handle)
MC-B5-T3 (Ball Handle) or MC-T5-T3 ("T" Handle)
MC-B5-T3D (Ball Handle) or MC-T5-T3D ("T" Handle)
System Parts List
Copper Tubing
R-13 Reservoir & Charging Valve 1 1 1 1 1 1 1 1 1 1 1 1
MCVF-10 Charging Valve Fittings - - - - - - 1 1 1 1 1 1
MCVF-11 Charging Valve Fittings 1 1 1 1 1 1 - - - - - -
CL-B4 or Control-Left (Ball Handle) or 1 1 2 2 3 3 2 2 4 4 6 6
CL-T4 Control-Left ("T" Handle)
CR-B4 or Control-Right (Ball Handle) or 1 1 2 2 3 3 2 2 4 4 6 6
CR-T4 Control-Right ("T" Handle)
CDF-04 Dual Mounting Plate - 1 - 2 - 3 - 2 - 4 - 6
CF-05 Control Fittings 2 2 4 4 6 6 4 4 8 8 12 12
SS-04 Shift Slave 1 1 1 1 1 1 2 2 2 2 2 2
SSF-06 Slave Fittings 1 1 1 1 1 1 2 2 2 2 2 2
ST-06 Throttle Slave & Double 1 1 1 1 1 1 2 2 2 2 2 2
Pilot Check Valve
STF-13 Slave Fittings 1 1 1 1 1 1 2 2 2 2 2 2
ADDITIONAL REQUIREMENTS - NOT INCLUDED IN SYSTEMS
MCO-03 Hydraulic Fluid* 2 2 2 2 3 3 2 2 3 3 4 4
Copper Tubing, 5/16" O.D.* *As Required
COMPONENT DESCRIPTION
SINGLE ENGINE TWIN ENGINE
