Hynautic 04 Series - System Parts List - Nylon Tubing

Page 16 of 36 Pages
System Parts List
Nylon Tubing
R-13 Reservoir & Charging Valve 1 1 1 1 1 1 1 1 1 1 1 1
MCVF-04 Charging Valve Fittings - - - - - - 1 1 1 1 1 1
MCVF-05 Charging Valve Fittings 1 1 1 1 1 1 - - - - - -
CL-B4 or Control-Left (Ball Handle) or 1 1 2 2 3 3 2 2 4 4 6 6
CL-T4 Control-Left ("T" Handle)
CR-B4 or Control-Right (Ball Handle) or 1 1 2 2 3 3 2 2 4 4 6 6
CR-T4 Control-Right ("T" Handle)
CDF-04 Dual Mounting Plate - 1 - 2 - 3 - 2 - 4 - 6
CF-04 Control Fittings 2 2 4 4 6 6 4 4 8 8 12 12
SS-04 Shift Slave 1 1 1 1 1 1 2 2 2 2 2 2
SSF-04 Slave Fittings 1 1 1 1 1 1 2 2 2 2 2 2
ST-06 Throttle Slave & Double 1 1 1 1 1 1 2 2 2 2 2 2
Pilot Check Valve
STF-12 Slave Fittings 1 1 1 1 1 1 2 2 2 2 2 2
ADDITIONAL REQUIREMENTS - NOT INCLUDED IN SYSTEMS
MCEF-04 Extra Fittings Package 1 1 1 1 1 1 1 1 1 1 1 1
MCT-02 100' Nylon Tube 2* 2* 2* 2* 3* 3* 3* 3* 4* 4* - -
MCT-05 500' Nylon Tube - - - - - - - - - - 1* 1*
MCO-03 Hydarulic Fluid 2* 2* 2* 2* 3* 3* 2* 2* 3* 3* 4* 4*
*As Required
COMPONENT DESCRIPTION
MC-B4-S1 (Ball Handle) or MC-T4-S1 ("T" Handle)
MC-B4-S1D (Ball Handle) or MC-T4-S1D ("T" Handle)
MC-B4-S2 (Ball Handle) or MC-T4-S2 ("T" Handle)
MC-B4-S2D (Ball Handle) or MC-T4-S2D ("T" Handle)
MC-B4-S3 (Ball Handle) or MC-T4-S3 ("T" Handle)
MC-B4-S3D (Ball Handle) or MC-T4-S3D ("T" Handle)
MC-B4-T1 (Ball Handle) or MC-T4-S1 ("T" Handle)
MC-B4-T1D (Ball Handle) or MC-T4-T1D ("T" Handle)
MC-B4-T2 (Ball Handle) or MC-T4-T2 ("T" Handle)
MC-B4-T2D (Ball Handle) or MC-T4-T2D ("T" Handle)
MC-B4-T3 (Ball Handle) or MC-T4-T3 ("T" Handle)
MC-B4-T3D (Ball Handle) or MC-T4-T3D ("T" Handle)
SINGLE ENGINE TWIN ENGINE
