HySecurity SlideDriver 50 VF Series Programming & Operation Manual

www.hysecurity.com Display & Menu Options D0559 Rev. A 43
Installer Menu Setting Options Menu Tasks & Explanations STC Wire
Connections
DG 0 (OFF)
DUAL GATE
0 = solo operator (off)
1 = Secondary unit
2 = Primary unit
3 = Sally Port A
4 = Sally Port B
Establishes communication after wiring dual gate
connections between two operators in Primary/
Secondary or Sally Port site congurations.
This menu item appears if the sequenced gate
menu item (SG) is set at 0 (off).
Dual Gate COM
(Gate 1) to Dual Gate
COM (Gate 2)
A to A
B to B
SG 0 (OFF)
SEQUENCED GATE
0 = off
1 = Loop Layout/Site #1
2 = Loop Layout/Site #2
Establishes communication after wiring two or
more operators as sequential gates.
This menu item only appears if the Dual Gate
menu item (DG) is set at 0 (solo operator).
NOTE: Access the User Menu in both operators
and set a Close Timer.
Connect Dual Gate
COM (Trafc Gate) to
Dual Gate COM
(Security Gate)
A to A
B to B
CH 0 (AC)
CHARGER TYPE
0 = AC powered charger
1 = Solar powered charger
Does not appear on an AC-powered operator.
The menu item only appears when using the DC
Charger unit and designates the charger type.
FO 0 (DISABLED)
FIRE DEPT OPEN
0 = disabled
1 = enabled
Provides the Fire Dept. Open input. When set
to 1, the open signal received by the operator
overrides all photoelectric eyes and edge
sensors, and opens the gate. Pressing the Reset,
Open, or Reset button is required before the
gate can be closed.
+24V
Fire Dept Open (#24)
OC 0 (DISABLED)
EMERGENCY CLOSE
0 = disabled
1 = enabled
Enables the Emergency Close input. When set
to 1, the constant hold close overrides vehicle
detectors, photo eyes and edge sensors, and
closes the gate. Pressing the Reset button once
or the Open button twice is required before the
gate will open.
+24V
EMERG CLOSE (#23)
SE 2
IES SENSITIVITY
1 = maximum sensitivity
2 = moderate (default)
9 = lowest sensitivity
Adjusts the sensitivity of the internal inherent
sensor. Available settings are 1-9 with 9 being
the least sensitive.
SS 0
IES STOP ONLY
0 = (off) Stop and reverse for
2 seconds
1 = (on) stop only (NOTE: Functions
in usage class IV only)
Only available in Usage Class IV gate operators
and allows an option whereby the inherent
sensor will only stop the gate.
LC 0
LEAF DELAY CLOSE
0 = none
1 to 7 = ½ (minimum) to 3½
seconds (maximum) in ½-second
steps (for Primary/Secondary only)
Only appears if the gate operator is set up as
a Primary or a Secondary. Available settings
are 1-7. Each increment adds ½ second, to a
maximum of 3 ½ seconds time delay, before the
operator activates when commanded to close.
LO 0
LEAF DELAY OPEN
0 = none
1 to 7 = 1/2 (minimum) to 3 1/2
seconds (maximum) in 1/2 -second
steps (for Primary/Secondary only)
Only appears if the gate operator is set up as
a Primary or a Secondary. Available settings
are 1-7. Each increment adds 1/2 second (with a
maximum of 3 1/2 seconds) time delay following
a command to open before the operator
activates.
RT 0 (60 SECS)
MAXIMUM RUN TIME
0 = 60 Seconds max run
1 = 300 Seconds max run
Allows an optional setting of 300 seconds
if changed to [RT 1] as opposed to the
maximum run timer default setting of
60 seconds.
PO 0 (OFF)
PARTIAL OPEN
0 = none
7 to 99 seconds
Activates the partial open input and allows an
adjustable distance by setting the open duration.
The available time settings are 7-99 seconds.
The default setting [PO 0] leaves this input
inactive.
