HySecurity SlideDriver 50 VF Series Programming & Operation Manual

www.hysecurity.com Display & Menu Options D0559 Rev. A 45
Installer Menu Setting Options Menu Tasks & Explanations STC Wire
Connections
IR 1 REVERSE
INSIDE OBS LOOP
0 = Pause closing only
1 = Enable reversing to open
2 = Ignore and continue closing*
The default is for full reversal when the Inside
Obstruction Loop is triggered. A setting of 0
causes the gate to only pause when triggered.
Closure begins as soon as the loop is clear
again. *A setting of 2 is only available on CRASH
barriers and providesfor the most secure facilities
where it is essential that the loop trigger is
completely ignored and the gate continues
closing without pause or reversal.
INSIDE OBS LOOP
(#10)
COM or connection
to HY-5A detector
DL 1 STANDARD
DETECTOR LOGIC
1 = Standard
2 & 3 = Quick Close
4 = Full anti-tailgate
Determines how the operator responds to a tail
gate notication.
NOTE: Does not appear in barrier gate
operators.
RL 1 CLOSE LIM
RELAY 1 LOGIC
0 = Disabled
1 = Close limit active
(1 to 29 available)
Congures the function of the User 1 output
relay. It has the capacity to switch both AC and
DC loads and can be used for high voltage and/
or high current loads. Connect devices directly to
the top of the relay: COM and either NO and/or
NC contacts.
Multiple logic function options exist. Refer to
User Relays – Programming Procedure on
page 55.
User 1 Relay
R2 6 GATE LOCK
RELAY 2 LOGIC
0 = Disabled
1 to 29 available
Congures the function of the User 2 output
relay. It has the capacity to switch both AC and
DC loads and can be used for high voltage and/
or high current loads. Connect devices directly
to the top of the relay: COM plus NO and NC
contacts.
Multiple optional logic function options exist.
Refer to User Relays – Programming Procedure
on page 55.
User 2 Relay
R3 1 CLOSE LIM
RELAY 3 LOGIC
0 = Disabled
1 to 29 available
Relay 3 congures the function of the User 3
output relay, which is an electronic relay with
the capacity for switching a DC load only. In the
StrongArm M30/M50, Relay 3 is connected to
the gate LED lighting and does not appear as an
option in the Installer Menu.
User 3 Relay
R4 through R11
RELAY <n> LOGIC
0 = Disabled
1 to 29 available
Similar to Relay 1 Logic.
NOTE: The Hy8Relay
™
module option can
be purchased to provide an additional 8 relay
terminals. Relay #39 set aside for Factory Use.
COM
NOTE: R4 through
RB user relays on
7-segment display
TL 2 (45 SECS)
OPEN TIME ALERT
2 = 45 second delay
0 = 0s delay
1 = 15s
3 = 75s
4 = 105s
5 = 135s
This menu item only appears if the #8 User
Relay function has been selected. It adjusts the
time delay before activation of the User Relay
function.
User Relay
LT 3 (75 SECS)
LOITERING ALERT
3 = 75 second delay
0 = 0s delay
1 = 15s
2 = 45s
4 = 105s
5 = 135s
This menu item only appears if the #13 User
Relay function has been selected. It adjusts the
time delay before activation of the User Relay.
Refer to User Relays – Programming Procedure
on page 55.
User Relay
