Note: N: Number of the Apollo 5K units.
In a multi-unit setup, up to 12 units can be configured into Single-phase,
Split-phase, or 3-phase AC Output (Table 6.5). Possible configurations include:
• Up to 12 units can be stacked in parallel for Single-phase
• Up to 6 units for each of the Lines 1 and 2 for Split-Phase
• Up to 4 units each for the lines 1, 2, and 3 for 3-phase.
Note: Each Apollo outputs 25A max, so the max current of each line is 25A x N.
Power Supply Phase Instructions
Single-phase
120V 60Hz
Single Unit 120V/60Hz, 25A
Multi (N) Units N≤12
120V/60Hz, 25A x N
(Stack Power & current)
Split-phase
240V 60Hz
P1 (Phase 1) x N Units N≤6
Line 1, 120V/60Hz, 25A x N (Stack
Power & current)
P2 (Phase 2) x N Units N≤6
Line 2, 120V/60Hz, 25A x N (Stack
Power & current)
3-phase
208V 60Hz
P1 (Phase 1) x N Units N≤4
Line 1, 120V/60Hz, 25A x N
(Stack Power & current)
P2 (Phase 2) x N Units N≤4
Line 2, 120V/60Hz, 25A x N (Stack
Power & current)
P3 (Phase 3) x N Units N≤4
Line 3, 120V/60Hz, 25A x N (Stack
Power & current)
Table 6.5 Possible multi-unit configurations
