Hytera HD705 - Page 392

UHF5 (806-941MHz) Information Service Manual
382
No. Ref. No. Print No. Part No. Description
1007 U701 T1J 3606010000010 D/A converter
1008 U801 T4K 3602023005740 Audio amplifier
1009 U820 T2L 3616037000020 Switch IC
1010 U821 T2K 3613010000000 Baseband processor
1011 U9002 B1E 3605025000020 Operational amplifier
1012 U9003 B1C 5404000000060 Sensor
1013 X101 T1I 3701019250030 Crystal oscillator
1014 X201 B5J 3701327610060 Crystal
1015 X203 B3H 3701019250040 TCXO
1016 Z501 B3C 3804157560000 GPS filter
1017 Z9001 B3F 3802733540030 Crystal filter
1018 / / / Main board
PD70X/ PD70XG/ HD705/ HD705G Channel Board
No. Ref. No. Part No. Description
1 C1001 3101052710000 270PF
2 C1002 3101052710000 270PF
3 C1003 3101052710000 270PF
4 C1004 3101052710000 270PF
5 C1005 3101052710000 270PF
6 C1006 3101052710000 270PF
