Service Manual UHF5 (806-941MHz) Information
383
No. Ref. No. Part No. Description
7 C1007 3101052710000 270PF
8 C1010 3101052710000 270PF
9 C1011 3101052710000 270PF
10 C1012 3101052710000 270PF
11 C1015 3101051040060 0.1UF
12 C1016 3101051040060 0.1UF
13 C1017 3101051040060 0.1UF
14 D1001 3310040000000 ESD protection diode
15 D1002 3307120100050 LED
16 D1003 3310040000000 ESD protection diode
17 D1004 3310040000000 ESD protection diode
18 D1005 3310040000000 ESD protection diode
19 D1006 3310040000000 ESD protection diode
20 D1007 3310040000000 ESD protection diode
21 D1008 3310040000000 ESD protection diode
22 D1009 3399040600020 ESD protection diode
23 D1011 3310040000000 ESD protection diode
24 D1013 3399040600020 ESD protection diode
25 D1014 3310040000000 ESD protection diode
26 J1001 5201016100040 Board-to-board connector
27 L1001 3221506181000 Bead
