Hytera PD415 - Page 116

UHF1 (400
‐
470 MHz)
Parts List
50
No. Ref No.
Print
No.
Part No. Description No. Ref No.
Print
No.
Part No. Description
107
C203
T3J
3101071060010
10uF
605
L903
T2I
3221505121010
Ferrite bead
108
C206
T3J
3101071060010
10uF
606
L904
T1I
3221505121010
Ferrite bead
109
C208
T3I
3101051040060
0.1uF
607
L905
T1J
3221505121010
Ferrite bead
110
C209
T3J
3101011030050
0.01uF
608
L906
T1J
3221505121010
Ferrite bead
111
C210
T3I
3101052730000
0.027uF
609
L907
T1J
3213306561000
0.56uH
112
C211
T3I
3101071060010
10uF
610
L909
T2I
3221505121010
Ferrite bead
113
C212
T3J
3101051040060
0.1uF
611
Q1001
B2H
3408002000080
NPN transistor
114 C214 T3J 3101051040060 0.1uF 612 Q1002 B2H 3403999000070
Compound
transistor
115
C215
T3J
3101013300010
33pF
613
Q1003
B2H
3403003000060
NPN transistor
116 C216 T3J 3101013300010 33pF 614 Q1004 B2I 3403999000070
Compound
transistor
117 C217 T3J 3101013300010 33pF 615 Q1005 B2H 3403999000070
Compound
transistor
118
C218
T3J
3101013300010
33pF
616
Q1006
B3H
3408002000000
NPN transistor
119
C219
T4I
3101071060010
10uF
617
Q1007
B3H
3401002000990
NPN transistor
120
C220
T3J
3101051040100
0.1uF
618
Q101
B3K
3503010000010
P-MOSFET
121
C221
T4J
3101051040060
0.1uF
619
Q1010
B2I
3408002000080
NPN transistor
122 C222 T4J 3101051040060 0.1uF 620 Q1011 B3H 3403999000070
Compound
transistor
123 C223 T4J 3101011040090 0.1uF 621 Q103 T2B 3503040000000
Compound
MOSFET
124
C224
B2J
3101011040090
0.1uF
622
Q301
T2F
3505990000040
P-MOSFET
125
C226
T3J
3001051020000
1KΩ
623
Q304
T4G
3599990000610
N-MOSFET
126
C227
T3J
3101011040090
0.1uF
624
Q401
T2C
3505990000040
P-MOSFET
127
C228
T3J
3101011040090
0.1uF
625
Q402
T4D
3505990000040
P-MOSFET
128 C231 T3J 3101011040090 0.1uF 626 Q403 T3G 3403008000010
Bias resistor
transistor
129
C232
T3J
3101011040090
0.1uF
627
Q404
T4D
3599990000610
N-MOSFET
130
C233
T4J
3101011040100
0.1uF
628
Q405
T4D
3401001000490
PNP transistor
131
C235
T3I
3101014710020
470pF
629
Q406
T4C
3599990000610
N-MOSFET
132
C236
T3I
3101011040100
0.1uF
630
Q502
T3H
3401002000990
NPN transistor
133 C237 B2K 3101011040090 0.1uF 631 Q504 T4G 3403007000020
Bias resistor
transistor
134 C238 T2K 3101011040090 0.1uF 632 Q601 B3C 3403999000070
Compound
transistor
135
C239
B2K
3101014710020
470pF
633
Q602
B3D
3418001000010
NPN transistor
136
C240
T2K
3101011040090
0.1uF
634
Q604
T3G
3401002000990
NPN transistor
137 C241 T2K 3101014710020 470pF 635 Q701 T1G 3403014000020
Compound
transistor
138 C242 T2K 3101011040090 0.1uF 636 Q702 T2G 3403008000010
Bias resistor
transistor
139 C243 B2K 3101014710020 470pF 637 Q703 T2G 3403999000070
Compound
transistor
140 C244 T2K 3101011040090 0.1uF 638 Q801 B1G 3403999000070
Compound
transistor
141
C245
T2K
3101014710020
470pF
639
Q802
B1F
3504990000010
PA MOSFET
142
C246
T2K
3101011040090
0.1uF
640
Q803
B1E
3504990000070
N-MOSFET
143
C247
T2K
3101014710020
470pF
641
Q804
B1G
3420999000060
NPN transistor
144 C248 T2K 3101011040090 0.1uF 642 Q901 T2H 3403999000070
Compound
transistor
145
C249
T2K
3101014710020
470pF
643
R1001
B2H
3001053320010
3.3KΩ
146
C250
T2K
3101011040090
0.1uF
644
R1002
B2H
3001014720050
4.7KΩ
147
C251
B2K
3101011040090
0.1uF
645
R1003
B2H
3001018230000
82KΩ
148
C252
B2J
3101014710020
470pF
646
R1004
B2I
3001011020060
1KΩ
149
C253
B2K
3101011040090
0.1uF
647
R1005
B1H
3001058220010
8.2KΩ
150
C254
B2J
3101014710020
470pF
648
R1006
B2H
3001011010080
100Ω
151
C255
T2K
3101011040090
0.1uF
649
R1007
B2I
3001018230000
82KΩ
152
C256
B2J
3101014710020
470pF
650
R1008
B2I
3001011020060
1KΩ
153
C257
B2K
3101011040090
0.1uF
651
R1009
B2H
3001018230000
82KΩ
154
C258
B2K
3101014710020
470pF
652
R101
B3K
3001011010080
100Ω
