4. Specifications
General
Frequency Range 136‐174 MHz
Channel Capacity 256
Channel Spacing 25 kHz/12.5 kHz
Operating Voltage 7.4 V (rated)
Battery 1500 mAh Li-Ion battery
Battery Life (5-5-90 Duty Cycle, High TX Power)
High-capacity 1800 mAh Li-Ion Battery
Analog: about 12 h
Digital: about 16 h
Operating Temperature -30
o
C to +60
o
C
Dimensions (H*W*D)
(with standard battery, without antenna)
112 mm * 55 mm * 31 mm
Weight (with antenna and standard battery) About 270 g
Frequency Stability ±0.5 ppm
Receiver
Sensitivity
Analog
0.22 μV (12 dB SINAD)
0.22 μV (Typical) (12 dB SINAD)
0.4 μV (20 dB SINAD)
Digital 0.22 μV/BER 5%
Rated Audio Power Output 0.5 W (16 Ω load)
Rated Audio Distortion ≤3%
