Item Method
3. Press the Enter key on the keyboard to confirm your settings.
Voltage
1. Connect the antenna connector of the radio to the RF port of HP8921,
and set HP8921 to TX test mode.
2. Open the Tuner software and go to “TUNE_DATA -> TX -> Receive
Oscillator Voltage” in the left navigation tree.
3. Click the “Save” button to save the tuned value to the radio.
8.2.2 Testing the Radio
After tuning the radio, you need to test the digital RF signal of the radio.
Transmitting Performance
Step 1 Open the Tuner software and go to “TEST -> TX -> Transmit BER (0.153)”.
Step 2 Select the channel to be tested and select “High Power” in the “Parameter”.
Step 3 Set Aeroflex 3920 as follows:
Frq: Be consistent with the frequency to be tested.
STD IB 511 (.153)
Step 4 Click the “Transmit On” button on Tuner.
