Hytera PD415 - Page 61

VHF1 (136
‐
174 MHz)
Parts List
54
No. Ref No.
Print
No.
Part No. Description No. Ref No.
Print
No.
Part No. Description
343
C655
T4F
3101050500000
5pF
857
R413
T4D
3001054730010
47KΩ
344
C656
B5F
3101056800000
68pF
858
R414
T3G
3001051020000
1KΩ
345
C657
B3G
3101051020010
1000pF
859
R415
T5D
3001050000000
0Ω
346
C658
B3G
3101053390050
3.3pF
860
R416
T4D
3001051020000
1KΩ
347
C659
B3G
3101051800010
18pF
861
R417
T4E
3001051010040
100Ω
348
C660
B3G
3101051000020
10pF
862
R418
T3E
3001051030050
10KΩ
349
C661
T3F
3101014710020
470pF
863
R419
T4E
3001051030050
10KΩ
350
C663
B3G
3101052000020
20pF
864
R420
T3E
3001052240000
220KΩ
351
C664
B3G
3101051500020
15pF
865
R421
T4E
3001051020000
1KΩ
352
C665
T3G
3101014710020
470pF
866
R422
T3E
3001054730010
47KΩ
353
C666
B2D
3101014710020
470pF
867
R423
T3E
3001051050000
1MΩ
354
C667
T3G
3101011040100
0.1uF
868
R424
T4E
3001051030050
10KΩ
355
C670
T4F
3101050600010
6pF
869
R425
T4E
3001051020000
1KΩ
356
C671
B3C
3101014710020
470pF
870
R426
T3E
3001054730010
47KΩ
357
C701
T2G
3101054710010
470pF
871
R427
T4E
3001051010040
100Ω
358
C702
T1F
3101051020010
1000pF
872
R428
T3E
3001051030050
10KΩ
359
C7020
B1D
3101063000010
30pF
873
R429
T4E
3001051020000
1KΩ
360
C7022
B1C
3101060500010
5pF
874
R430
T4D
3001051020000
1KΩ
361
C703
T2F
3101061020000
1000pF
875
R432
T3E
3001052220000
2.2KΩ
362
C7035
B1D
3101060700020
7pF
876
R433
T3C
3001053310000
330Ω
363
C7036
B1B
3101061000000
10pF
877
R434
T3E
3001051040000
100KΩ
364
C7040
B1C
3101060500010
5pF
878
R435
T4D
3001052230010
22KΩ
365
C7044
B1D
3101060700020
7pF
879
R436
T4D
3001052220000
2.2KΩ
366
C7046
B1C
3101061100010
11pF
880
R437
T3C
3001051030050
10KΩ
367
C705
T1G
3101064710000
470pF
881
R438
T4C
3001051030050
10KΩ
368
C7065
B1D
3101066800000
68pF
882
R439
T3C
3001055630010
56KΩ
369
C7066
B1C
3101062200010
22pF
883
R440
T4D
3001051050000
1MΩ
370
C707
T2G
3101052210010
220pF
884
R442
T4D
3001051020000
1KΩ
371
C708
T1G
3101054710010
470pF
885
R443
T4D
3001051020000
1KΩ
372
C709
T1G
3101053340000
0.33uF
886
R444
T2C
3001050000000
0Ω
373
C714
T3G
3101052210010
220pF
887
R503
T3H
3001051010040
100Ω
374
C801
B1G
3101011040100
0.1uF
888
R504
T3G
3001054790000
4.7Ω
375
C802
B1G
3101014710020
470pF
889
R507
T3H
3001053340010
330KΩ
376
C803
T2E
3101054710010
470pF
890
R508
T2H
3001012220010
2.2KΩ
377
C804
T3E
3101051040060
0.1uF
891
R510
T4H
3001052730000
27KΩ
378
C805
B3E
3101051020010
1000pF
892
R511
T4H
3001053320010
3.3KΩ
379
C806
B3E
3101054700010
47pF
893
R513
T4H
3001051520000
1.5KΩ
380
C807
B2E
3101051020010
1000pF
894
R514
T4H
3001051520000
1.5KΩ
381
C808
B2E
3101051040060
0.1uF
895
R601
B3C
3001058230000
82KΩ
382
C809
T2E
3101081060010
10uF
896
R602
B3C
3001051010040
100Ω
383
C810
T1C
3101051020010
1000pF
897
R6029
T3F
3001011030080
10KΩ
384
C811
T1C
3101051040060
0.1uF
898
R603
B3D
3001051030050
10KΩ
385
C814
B3C
3101060300010
3pF
899
R605
B3D
3001055610000
560Ω
386
C815
B3B
3101060600010
6pF
900
R606
B3C
3001055620010
5.6KΩ
387
C816
B3C
3101063690000
3.6pF
901
R607
B3D
3001050100010
1Ω
388
C817
B1F
3101051020010
1000pF
902
R608
B4E
3001011040030
100KΩ
389
C823
B1C
3101062210000
220pF
903
R609
B4E
3001011040030
100KΩ
390
C824
B2C
3101061020000
1000pF
904
R610
B2D
3001011040030
100KΩ
391
C825
B3B
3101061020000
1000pF
905
R611
B3D
3001011040030
100KΩ
392
C826
B1E
3101065610000
560pF
906
R612
T3F
3001051030050
10KΩ
393
C833
B3C
3101061100010
11pF
907
R613
T2G
3001053310000
330Ω
394
C834
B3B
3101063000010
30pF
908
R614
T3G
3001053340010
330KΩ
395
C835
B3C
3101061500010
15pF
909
R618
B5F
3001055100020
51Ω
396
C838
B1E
3101061500010
15pF
910
R619
T3G
3001054730010
47KΩ
397
C839
B2B
3101062700010
27pF
911
R621
B2D
3001011040030
100KΩ
398
C843
B1F
3101053340000
0.33uF
912
R622
T3F
3001055630010
56KΩ
399
C844
B1E
3101051030020
0.01uF
913
R624
T3F
3001051040000
100KΩ
400
C845
B2C
3101051020010
1000pF
914
R625
T3F
3001051020000
1KΩ
401
C846
B3C
3101051000020
10pF
915
R631
B4E
3101053300000
33pF
402
C850
B1F
3101051020010
1000pF
916
R701
T2E
3099080398010
0.39Ω
