Hytera PD415 - Page 64

Parts List
VHF1 (136
‐
174 MHz)
57
No. Ref No.
Print
No.
Part No. Description No. Ref No.
Print
No.
Part No. Description
500 D604 B2D 3304010100180 Varactor 1014 U402 T4E 3605008005070
Operational
amplifier
501
D605
B4E
3304010100180
Varactor
1015
U501
T3H
3603018000000
IF processor IC
502
D606
B4E
3304010100180
Varactor
1016
U601
T3G
3616010000000
Switch IC
503 D607 B4F 3301250300000 Schottky diode 1017 U602 T3F 3605026002710
Operational
amplifier
504 D701 T2F 3303030800020 Switching diode 1018 U701 T2G 3605025000020
Operational
amplifier
505
D801
B2C
3303030800040
Switching diode
1019
U901
T2J
3604019000000
PLL IC
506
D803
B2C
3399030000010
PIN diode
1020
U902
T2I
3616059000000
Switch IC
507
D804
B2C
3399030000010
PIN diode
1021
U903
T1H
3616010000000
Switch IC
508 D901 T2I 3301990000030
Schottky barrier
diode
1022 X101 B4I 3701001260120 Crystal
509 D902 T2H 3301990000030
Schottky barrier
diode
1023 X201 T3J 3701122830020 TCXO
510 D903 T2H 3301990000030
Schottky barrier
diode
1024 X901 T1J 3701019250150 VC-TCXO
511
D904
T1I
3303030800020
Switching diode
1025
Z501
B4H
3801045030170
Ceramic filter
512 E T3H 6203694000000
IF shielding
cover
1026 Z502 B4G 3920450300020
Frequency
discriminator
513 F T2H 6203695000000
2NDLO shielding
cover
1027 Z601 T4F 3802388540020 Crystal filter
514
F301
T3F
4002000000320
Fuse
/
/
/
/
/
