Exploded View and Packing Guide
5
No. Part No. Description Qty. No. Part No. Description
Qty
.
10 1300D500U0020 Main Board 1 27 6001068000010 Code Switch 1
11 7500875000000 Filter Foam 1 28 6001978000000
Accessory Connector
Cover
1
12 6300269000000
Aluminum
Chassis
2 29 6202121000000 Speaker Fixing Sheet 1
13 6101037000000
Waterproof Ring
of Battery
Connector
1 30 5001210000720 Speaker 1
14 6100527100000
Waterproof Ring
for M2 Screw
2 31 7400741000000 Speaker Felt 1
15 7102506002100
Machine Screw
M2.5*6.0 mm
2 32 6101107000000
PTT Key (Silicone
Rubber)
1
16 7103007500000
Machine Screw
M3.0*7.5 mm
2 33 6002336000000 PTT Key Cover 1
17 6002449000000 Rear Cover 1 34 6002338000000
Transparent Light
Guide
1
Note
For parts that are not marked with Part Number, their Part Numbers may vary with the frequency
band.
