(3) Link connection for ERC2-SE

Gateway unit

(Incorporating

terminal resistor)

e-CON connector (AMP made 4-1473562-4: Green)

e-CON connector (AMP made 3-1473562-4: Orange)

Junction (AMP made 3-1473574-4:)

Recommended brand: Taiyo Electric Wire & Cable

SIO communication

main line

First axis

Second axis

axis

Terminal resistor
