IBC AHU Series User Manual

17
1.0 Introduction
The IBC air handling appliance is designed for ducted heating and cooling. The appliance provides up to
four mounting options for flexibility and ease of installation. Return air duct connections can be
connected left, right, and bottom to suit the appliance's mounting position. For information on mounting
positions and sizing, see Cabinet and air supply dimensions on page 9.
Appliances installed with a right side air opening will require the air filter position to be modified. For
instructions, see Repositioning the air filter brackets on page 24.
1.1 Standard features and benefits
Integrated air handling appliance
High efficiency motor with variable speed (ECM) centrifugal fan
Quiet operation
Slide out fan assembly
Optional filter rack positioning
High efficiency fin tube coil
