Specification AHU 800 AHU 1200 AHU 1600
Max. water temperature (°F/C°) 195 / 90
Coil performance at 180°F (Btu/hr) 66,800 80,600 99,300
Water pipe connections (inches) ¾ MPT
External static pressure (" wc) 0.50
Max. operating water pressure (PSI) 150
Width (inches) 17.5 21 24.5
Depth (inches) 26
Height (inches) 32 38 42
Supply air opening width (inches) 16 19.6 23
Supply air opening depth (inches) 19.6
Side return air opening height (inches) 7 10.5 13
Side return air opening width (inches) 23
Bottom return air opening width (inches) 13 10.5 14
Bottom return air opening depth
(inches)
23
Max. internal current power rating
120Volts (Amp)
2.4
External pump supply 120V (Amp) 5
Voltage (V) 120
Max. air flow @ rated static pressure
(CFM)
1138 1334 2900
Maximum return air temperature (°F/C°) 122 / 50
Filter size (MERV 8) (inches) 16 x 25 x 1 25 x 20 x 1 (not
included)
25 x 20 x 1 (not
included)
