IBC AHU Series User Manual

Multi-position configurations
Industry standard duct sizes – supply air opening compatible with cased and uncased A/C
and heat pump coils
Single stage or 2-stage heating and cooling
Compact design for those awkward spaces; the ability to orient horizontally or vertically
Heat pump capable
Control for external pump (5A - 120V)
Flexible electrical connection knock-outs on left and right sides
Standard thermostat capable
OpenTherm thermostat capable
WiFi connection for programming with the IBCconnect mobile app
Sensors for protection and operation:
Included - sensors for supply air, return air, supply water, return water, humidifier, de-
humidifier, and frost protection
Not included - (optional)outdoor sensor (IBC Part # 240-025), air conditioning coil
supply, air sensor kit
Maximum return air temperature 122°F (50°C)
1.2 Conformity
Installation must conform to the requirements of the authority having jurisdiction. In the absence of
such requirements, the installation must conform to the National Electrical Code ANSI/NFPA No.
70, current edition.
