IBC AHU Series User Manual

Item Number P-Kit Number Description
100 P-1000 Door assembly - AHU 800
P- 1019 Door assembly - AHU 1200
P-1022 Door assembly - AHU 1600
110 P-1001 Air filter size 25 x 16 x 1 - AHU 800
Air filter size 25 x 20 x 1 - AHU 1200, - AHU 1200
120 P-1008 Door switch, SPST-NO. 15A 125V
120 Wiring harness
130 P-1011 Supply water temperature sensor
140 P-1012 Temperature sensor and grommet
150 P-1011 Return water temperature sensor
160 P-1003 Hot water coil 2-ton appliance - AHU 800
P-1020 Hot water coil 3-ton appliance - AHU 1200
P-1022 Hot water coil 4-ton appliance - AHU 1600
170 P-1005 Transformer 40VA 120V
180 P-1001 Control board
190
P-1007
Filter bracket wing nuts x 4
200 Air filter lower bracket
210 Air filter upper bracket
220
P-1017 Coil hex bolts, hex nut, washer x 2
Fan plate hex bolts, washer x 2
230
P-1004
P-1021
P- 1024
Fan and motor assembly - AHU 800
Fan and motor assembly - AHU 1200
Fan and motor assembly - AHU 1600
240 Fan wiring grommet
250 P-1009 Sensor wiring harness
260 P-1017 Door thumb screws x 2
* P-1017 = Part of the hardware kit
71
Air handling appliance - parts diagram
