Figure 49. Removing the PCIe riser screws
6. Lift the PCIe riser from the system and place it on an ESD surface.
Replacing the PCIe riser in the 7063-CR2 system
To replace the PCIe riser in the IBM Power Systems HMC (7063-CR2) system, complete the steps in this
procedure.
Procedure
1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged
into a ground jack or connected to an unpainted metal surface. If not, do so now.
2. Install the PCIe riser into the system. Insert the PCIe riser into the system backplane until the riser
card is fully seated in the socket on the backplane.
3. Replace the four screws to secure the PCIe riser to the system backplane.
Removing and replacing parts in the 7063-CR2
39
