Figure 92. Opening the system processor module packaging

5. Loosen the load arm screw (A) of the system processor heat sink (B) that you are removing with a T20

hexalobular driver. The load arm pivots up in the direction that is shown in the following gure.

Power Systems: Servicing the IBM Power Systems HMC (7063-CR2)
