Shipment weights and dimensions
You must ensure that your loading dock and receiving area can support the weight and dimensions of the
packaged storage system shipments.
You receive at least two, and up to three, shipping containers for each model that you order. You always
receive the following items:
• For model 993, a container with the storage system modules, or for models 994, 996, and E96, a
container with the storage system frame. In the People's Republic of China (including Hong Kong S.A.R.
of China), India, and Brazil, this container has a plywood front door on the package, with a corrugated
paperboard outer wrap. In all other countries, this container is a pallet that is covered by a corrugated
berboard (cardboard) cover
• A container with the remaining components, such as power cords, CDs, and other ordered features or
peripheral devices for your storage system.
Table 41 on page 80 shows the nal packaged dimensions and maximum packaged weight of the
storage system frame shipments.
To calculate the weight of your total shipment, add the weight of each frame container and the weight of
one ship group container for each frame.
Table 41. Packaged dimensions and weight for storage system frames (all countries)
Container Packaged dimensions Maximum packaged
weight
DS8910F Rack Mounted model 993
Height
1.49 m (58.7 in.)
Width
1.05 m (41.3 in.)
Depth
1.30 m (51.2 in.)
295 kg (650 lb)
DS8910 base frame model 994
Height
2.22 m (87.7 in.)
Width
1 m (39.4 in.)
Depth
1.50 m (59.1 in.)
762 kg (1680 lb)
DS8950 base frame model 996
Height
2.22 m (87.7 in.)
Width
1 m (39.4 in.)
Depth
1.50 m (59.1 in.)
793 kg (1748 lb)
DS8950 expansion frame model E96
Height
2.22 m (87.7 in.)
Width
1 m (39.4 in.)
Depth
1.50 m (59.1 in.)
603 kg (1330 lb)
80 IBM DS8900F: DS8900F Introduction and Planning Guide
