Chapter 2. Hardware features

Use this information to assist you with planning, ordering, and managing your storage system.

The following table lists feature codes that are used to order hardware features for your system.

Table 12. Feature codes for hardware features

Feature

code Feature Description

0200 Shipping weight reduction Maximum shipping weight of any storage

system base model or expansion model

does not exceed 909 kg (2000 lb) each.

Packaging adds 120 kg (265 lb).

0400 BSMI certication documents Required when the storage system model

is shipped to Taiwan.

0403 Non-encryption certication key Required when the storage system model

is shipped to China or Russia.

0937 zFlex Frame eld merge Indicates that the model 993 will be

installed in an existing IBM Z model ZR1

rack

0938 Rockhopper II eld merge Indicates that the model 993 will be

installed in an existing IBM LinuxONE

Rockhopper II model LR1 rack

0939 Customer Rack eld merge Indicates that the model 993 will be

installed in an existing standard 19-inch

wide rack that conforms to EIA 310D

specications

0990 On-site code load Required to opt out of remote code load

(feature code 0991). If selected, IBM

modies the relevant machine record

accordingly.

0991 Remote code load (default) Indicates that the storage system code

loads are done remotely. This is the default

option between feature codes 0990 and

0991.

1014 Front and rear door lock and key kit

1038 Single-phase power cord, 208 V, 30 A NEMA L6-30P 2P+Gnd

1039 Single-phase power cord, 250 V, 32 A IEC 309 P+N+Gnd

1040 Three-phase power cord, 250 V, 60 A IEC 309 3P+Gnd (four-pin Delta)

1041 Three-phase power cord, 250 V, 32 A IEC 309 3P+N+Gnd (ve-pin Wye)

1042 Single-phase power cord, 250 V, 32 A For use in Australia and New Zealand (not

IEC 309)

1043 Single-phase power cord, 250 V, 30 A For use in Korea

1044 Single-phase power cord, 250 V, 32 A IEC 309 P+N+Gnd (halogen free)

IBM DS8900F User Manual
