IBM Elastic Storage System 3200 User Manual

ESS 3500 Building-Block 2 (higher position in frame)
Note: ESS 3500 only applies to ESS 6130 and later.
IP address Netmask
ESS 3500 canister 1
management interface (left)
192.168.45.32 255.255.255.0
ESS 3500 canister 1 BMC
interface (left)
10.0.0.123 255.255.255.0
ESS 3500 canister 2
management interface (right)
192.168.45.33 255.255.255.0
ESS 3500 canister 2 BMC
interface (right)
10.0.0.124 255.255.255.0
The VLAN tag is required to route trafc on the BMC interface to the service network. This interface is
connected to the green trunk ports on the switch. This is required only on ESS 3200 and ESS 3500. The
default is 101.
ESS 3200/3500 VLAN Tag VLAN TAG 101
ESS 3200 Building-Block 1 (lowest position in frame)
IP address Netmask
ESS 3200 canister 1
management interface (left)
192.168.45.40 255.255.255.0
ESS 3200 canister 1 BMC
interface (left)
10.0.0.131 255.255.255.0
ESS 3200 canister 2
management interface (right)
192.168.45.41 255.255.255.0
ESS 3200 canister 2 BMC
interface (right)
10.0.0.132 255.255.255.0
ESS 3200 Building-Block 2 (higher position in frame)
IP address
Netmask
ESS 3200 canister 1
management interface (left)
192.168.45.42 255.255.255.0
ESS 3200 canister 1 BMC
interface (left)
10.0.0.133 255.255.255.0
ESS 3200 canister 2
management interface (right)
192.168.45.43 255.255.255.0
ESS 3200 canister 2 BMC
interface (right)
10.0.0.134 255.255.255.0
The VLAN tag is required to route trafc on the BMC interface to the service network. This interface is
connected to the green trunk ports on the switch. This is required only on ESS 3200 and ESS 3500. The
default is 101.
ESS 3200/3500 VLAN Tag
VLAN TAG 101
ESS 5000 Building-Block 1 (lowest position in frame)
104
IBM Elastic Storage System 3200: Hardware Planning and Installation Guide
